⚠️ Safety Critical Protocol: UIC 812-4 governs the marriage of the tyre to the wheel centre. Unlike monobloc wheels, this assembly relies on friction. Failure to strictly follow the “Shrink-Fit” temperature and interference rules can lead to “Tyre Displacement” during braking, a major cause of derailments.

Assembling a tyred wheel is a precise thermal operation. UIC 812-4 defines the technical specifications for fitting tyres onto wheel centres for tractive and trailing stock, ensuring that the assembly acts as a single solid unit under dynamic loads.

1. The Assembly Process: Shrink-Fitting

The tyre is held in place not by bolts or welds, but by the compressive force of the steel contracting.

  • Interference Value ($i$): The internal diameter of the cold tyre is intentionally smaller than the external diameter of the wheel centre (typically $1/1000$ of the diameter).
  • Heating: The tyre is heated (expanded) to slip over the centre. UIC 812-4 mandates:
    • Maximum Temperature: Generally < 250°C.
    • Why? Exceeding this temp alters the tempered microstructure of the steel, ruining its hardness.

2. Securing the Tyre: The Retaining Ring

Friction alone is often considered insufficient for safety, especially if the wheel overheats during braking.

  • Gibson Ring (Retaining Ring): A locking ring is inserted into a groove on the tyre’s outer edge and rolled down to mechanically lock the tyre to the centre.
  • Function: It prevents the tyre from coming off laterally if the shrink-fit loosens due to thermal expansion (e.g., stuck brake blocks).

3. Geometric Tolerances (Acceptance)

Once assembled, the wheelset must meet strict dimensional checks before going under a train.

ParameterDefinitionCritical Limit
Back-to-Back DistanceDistance between the inner faces of the tyres.1360 mm ± 3 mm (Standard Gauge). Critical for switch navigation.
Radial Run-outOut-of-roundness of the tread.Typically ≤ 0.5 mm to prevent vibration.
Axial Run-outWobble of the rim face.≤ 1.0 mm (slightly looser than monoblocs).

4. Monitoring in Service: Creep Marks

UIC 812-4 (and maintenance manuals) requires a visual safety indicator on the finished assembly.

  • The Registry Marks: Small paint marks (usually white or yellow) painted across the junction of the tyre and the wheel centre.
  • Inspection: Maintenance staff visually check these marks. If the lines are misaligned, it means the tyre has rotated (“crept”) on the centre.Action: The vehicle must be immediately removed from service.


Engineering Note: Tyred wheels are generally restricted to speeds below 120 – 160 km/h. For higher speeds, monobloc wheels (UIC 812-3) are mandatory due to the absence of the risk of tyre loosening.
